Description
ENI 2100L RF Power Amplifier, 250 kHz to 150 MHz, 100 W, 50 dB
The 2100L is a class A power amplifier. The 2100L is designed for RFI/EMI applications as well as general laboratory purposes. The 2100L delivers low distortion amplification over the entire useful frequency range.
Features:
- Frequency Range: 250 kHz to 150 MHz
- 100 W output power
- 50 dB gain (nominal)
- Front panel metering
- 50 Ohm impedance
- N(f) connectors, input/output
- 115/230 Vac; 47-63 Hz operation
- Weight: 35 lb; Size: 134.5 mm (5.3 in)H x 420 mm (16.5 in)W x 467 mm (18.4 in)D
Please see Datasheet for complete details and specifications.
