Narda 4034C 90° Coaxial Mini-Hybrid, 4.0 to 8.0 GHz, SMA(f)
The 4034C SMA Miniature Stripline 90° Coaxial Mini-Hybrid covers 4.0 to 8.0 GHz and features SMA(f) connectors.
- Frequency Range: 4.0 to 8.0 GHz
- Nominal Coupling: 3 dB
- VSWR (max.): 1.25
- Insertion Loss: 0.3 dB (max.)
- Isolation: 20 dB (min.)
- Average Power: 50 W
- Operational to 105°C without Degradation (125°C Storage)
Please see Datasheet for complete details and specifications.
